General Description:
We can provide a choice of different face to face dimensions for DIN/EN cast steel globe valve. It has good sealing performance and longer service life, which is suitable for industry, power system, exhaust gas purification device, hot water, heat transfer oil application, shipbuilding industry, etc.

Design Standard:
Basic Design: EN 13709
Face – Face Dimension: EN 558-1 GR.1 / 2, DIN 3202-F1 / F2, ISO 5752
End – End Dimension: EN 12627
Flange Dimension: EN 1092-1
Test: EN 12266, ISO 5208

Products Range:
Size: DN 15 ~ DN400
Rating: PN16 ~ PN160
Body Materials: Carbon Steel, Stainless Steel , Alloy Steel, Duplex Steel
Trim: Per API 600
Operation: Handwheel, Gear, Motor, Pneumatic

Design Feature:
Low emission control
Integral body seat
Plug or throttling disc
Optional Impact hand wheel

FAQ:
Q: Can you do customized design and size?
A: Yes, ODM & OEM service are available.
Q: What is the delivery time?
A: We have a lot of stock valves, covering various sizes, pressures and materials to ensure the fast delivery.
Q: What is the warranty?
A: One year after shipping.
